Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 Or ISO 2248 ISTA

Name: Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 Or ISO 2248 ISTA
Brand: LABTONE
Price: 1 USD

Quality Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 Or ISO 2248 ISTA for sale

Brand Name : LABTONE

Model Number : DT150

Certification : CE ISO

Place of Origin : CHINA

MOQ : 1set

Price : Negotiable

Payment Terms : T/T

Supply Ability : 50 Sets / Month

Delivery Time : 15-20 days

Packaging Details : international wooden case

Drop height : 300-1500mm

Specimen weight : 85kg

Specimen dimension : 800*800*800mm

Drop mode : freedom

machine dimension : 1700*1200*2750mm

machine weight : 550kg

Warranty : 12 Months

Air pressure : 0.5-0.7Mpa

Name : Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 or ISO 2248 ISTA

Contact Now

Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 or ISO 2248 ISTA

Introduction

DT Series of drop tester is designed according to industry data and international testing standards. It complies with ISTA, ASTM, ISO, MIL-STD, JIS, and other international test standards. DT Series performs face, corner, and edge drop tests to make a complete evaluation of the performance of package and product.

This model can be installed to any location and is easy to use by anyone, You will be able to carry out drop testing for your packaging design anytime anywhere.

Specifications

Model	DT150	DT200
Drop height range (mm)	300---1500	300----2000
Specimen max.weight (kg)	85	85
Specimen max. size (mm)	800800800	800800800
Drop mode	Freedom
Machine Dimension (mm)	150010002150	170012002750
Machine weight (kg)	480	550
Power supply	AC220V 50Hz compressed air 0.5~0.7Mpa
Standards	ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27

Functions and Features

Meets GB, IEC, ASTM, ISTA, ISO, JIS, TAPPI, and other industrial standards
Exclusive hand-held operator control
Precision Servo ball screw drive system
Steel base plate
Edge & corner fixture
Can perform surfaces, corner, and edge drops
Unique swing arm structural design, escape acceleration of swing arm greater than 3G.
With a double-column guide, the hydraulic buffer will absorb the dynamic force of the swingarm, such that the movement is stable, reliable with low noise.
Self-locking screw-in lifting mechanism to prevent accidental downward glide.
Automatic pneumatic interlocks to prevent abnormal detachment of swing arm.
Easy Maintenance for long term usage.

Free Fall Drop Tester For Packaging Drop Test Meets ASTMD5276 Or ISO 2248 ISTA

Packaging

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency, etc
